As built floor plans
Dimensioned plans showing walls, openings, columns, fixtures and levels for every floor in scope.
2D Documentation
Point cloud to 2D CAD drawings that are dimensioned, layered and ready to issue
Not every project needs a BIM model. When you just need accurate drawings of what is there, we produce clean layered DWG files straight from the scan data.
Named project lead
Fixed price, fixed date
Service snapshot
What a typical engagement looks likeOutputDWG, DXF, PDF
Turnaround2 to 4 days per floor
StandardsYour CAD layer standard
Scales1 to 50, 1 to 100 and detail scales
IncludesDimensions and annotation
Request pricing for this service
No obligation. Most quotes go out within 24 hours.
Overview
Sometimes the fastest route to a decision is a good drawing
Leasing plans, permit submissions, small fit outs and equipment layouts often need dimensioned 2D output and nothing more. Paying for a full BIM model in those cases is wasted budget.
We cut sections through the registered cloud and draft accurate plans, elevations and sections in AutoCAD, using your layer standard and your titleblock. If your project later needs full 3D, the same registered cloud carries straight into point cloud to BIM modeling with no rework.
- Drafted from measured scan data, not redrawn from old files
- Your layer naming, line weights and text styles applied
- Fully dimensioned with grid and level references
- Delivered as DWG plus PDF for issue
Why choose us
Drafting accuracy you can state on the sheet, not just claim
2D output is often treated as an afterthought. We treat the tolerance and the standard match as the whole point.
01
5 mm to 10 mm drafted accuracy
Stated on every sheet, not left implied
You know exactly what tolerance the drawing was measured to before you rely on it for a design decision.
02
Your CAD standard matched
Layers, weights and blocks mirrored exactly
Send a sample drawing or a CTB file and we match it, rather than asking your team to adapt to ours.
03
2 to 4 day turnaround
Per floor, from registered scan to issued sheet
Fast enough to support a tight leasing, permit or tender deadline without cutting the standard.
04
BOMA and IPMS ready
Area calculation method stated on the sheet
Measured to whichever standard your leasing or planning process requires, with the method noted for audit.
What you get
Drawings we produce from point cloud data
Pick the sheets you need. Each one is drafted from the same verified data set.
Reflected ceiling plans
Ceiling grids, heights, light fittings, diffusers and access panels mapped from the scan.
Sections and elevations
Cut lines taken through the cloud with true heights, floor to floor dimensions and facade detail.
Site and roof plans
External layout, roof geometry, plant positions, levels and immediate site context.
Enlarged detail drawings
Cores, toilets, plant rooms and any zone that needs a larger scale to be useful.
Layered DWG package
Files organised to your layer standard with consistent line weights, blocks and text styles.
Scope of work
What appears on the drawings
Confirm the annotation set at quote stage and it is fixed for the whole project.
Included in every project
- Wall lines with measured thickness
- Door and window openings with sizes
- Column positions and grid references
- Floor levels and change of level markers
- Ceiling heights and ceiling grid layout
- Sanitary ware and fixed fittings
- Visible services and plant positions
- Room names, numbers and areas
- Overall and running dimensions
- North point, scale bar and titleblock
| Scope item | What we deliver | Typical use |
|---|---|---|
| Floor plans | Dimensioned plans at your chosen scale | Fit out, leasing and permit sets |
| Ceiling plans | Grid, heights, fittings and access points | Services and lighting design |
| Sections | Vertical cuts with measured floor to floor heights | Height studies and equipment fit |
| Elevations | Facade drawings with openings and features | Facade repair and planning submissions |
Need both. Many clients order 2D drawings for immediate use and a BIM model for the longer programme. Bundled together, the drawings are produced from the same model, so the two never contradict each other.
How it works
How the drawings are produced
Every line is traceable back to a point in the cloud.
Confirm the drawing list
We agree sheet list, scales, layer standard, annotation style and titleblock before drafting starts.
Cut and extract
Horizontal and vertical slices are taken through the registered cloud at the agreed heights.
Draft in CAD
Lines are drafted onto the correct layers with consistent weights, then blocks and symbols are placed.
Dimension and annotate
Dimensions, levels, room data, references and notes are added to your annotation standard.
Check and issue
A second drafter checks every sheet against the cloud, then the package is issued as DWG and PDF.
Why clients pick us for this
Fast turnaround
Most floors delivered in under four days.
Your CAD standard
Layers and styles match your office rules.
Lower cost route
A fraction of the price of a full BIM model.
Case study
Forty eight stores, one drawing standard, six week programme
Retail · United Kingdom
The challenge
A national retail chain needed as built floor plans for 48 stores ahead of a rebrand programme, with a hard deadline set by the marketing launch date and almost no flexibility to slip.
What we did
We built one layer standard and one titleblock for the whole rollout, then processed stores in weekly batches of eight, cutting sections through each registered scan and issuing dimensioned DWG and PDF plans within four days of each store survey.
The result
48 stores delivered
Across a six week programme with zero missed batches
4 days per store
From scan data to an issued, dimensioned drawing set
Zero rebrand delays
Design team had every store plans ahead of the launch date
"Forty eight stores and every drawing looked like it came from the same hand. That consistency saved our design team weeks."
POP. OseiHead of Store Design, Retail Chain
Questions
Point Cloud to 2D CAD questions we hear most
Straight answers so you can scope your project with confidence.
Yes. Send your layer standard, a sample drawing or a CTB file and we match it exactly, including line weights, text styles, block names and dimension styles.
Drawing accuracy follows the scan data. Typical wall positions are within 5 mm to 10 mm, and we state the tolerance on every sheet so nobody assumes more precision than the data supports.
Yes. If a model already exists we generate the sheets from it, which keeps the drawings and the model permanently in step.
Yes. Every package includes issue ready PDFs at the agreed scale alongside the editable DWG files.
Yes. We produce area plans to BOMA, IPMS or your local measurement standard, with the calculation method stated on the sheet.
