Coordinated architecture model
Walls, floors, ceilings, roofs, doors, windows and vertical circulation, all in native Revit categories.
Architecture Discipline
Architectural scan to BIM built the way architects actually work
Real wall types with real layers. Doors and windows as families, not blocks. Rooms that schedule properly. A model your design team can push straight into the next phase.
Named project lead
Fixed price, fixed date
Service snapshot
What a typical engagement looks likeTypical LODLOD 200 to LOD 400
Turnaround3 to 5 days per floor
SoftwareRevit, ArchiCAD, IFC
DeliverablesRVT, IFC, DWG, sheet set
IncludesRoom and finish schedules
Request pricing for this service
No obligation. Most quotes go out within 24 hours.
Overview
Architecture models fail when they are drawn instead of built
Anyone can trace a point cloud outline and call it a wall. That model breaks the moment someone tries to change a wall type, cut a section or run an area schedule.
We build with the correct Revit categories from the start. Wall types carry their layers, doors sit in real openings, and levels match the floor to floor heights the scanner measured. Where a project also needs frame or services detail, this pairs directly with our structural scan to BIM and MEP scan to BIM services.
- Compound wall types with correct material layers
- Doors and windows as parametric families with real sizes
- Rooms, areas and finish schedules that populate on open
- Stairs, railings, ceilings and soffits modeled to shape
Scan
BIM Model
Drag the handle to compare the scan against the finished model
Why choose us
The difference between a traced outline and a real architectural model
These are the details a design team notices in the first ten minutes of opening the file.
01
Compound wall types
Real material layers, not single line walls
Wall types carry their actual layer buildup, so material takeoffs and sections are correct from the first day you open the file.
02
Custom families included
No extra charge for non standard doors and windows
Bespoke joinery, unusual openings and specialist fixtures are built as proper parametric families as part of the base price.
03
3 to 5 day floors
Typical turnaround per architectural floor
Fast enough that a design team is rarely left waiting on the next release to keep moving.
04
0 warnings guarantee
Rooms bounded, schedules populate on open
Area and room schedules are tested against a measured check before delivery, which matters when they feed a lease or a planning submission.
What you get
What lands in the architectural package
Design ready output, not a shell you have to rebuild.
Custom family library
Any door, window or joinery item that does not exist in your library gets built as a proper parametric family.
Room and area plans
Rooms named, numbered and bounded correctly so area schedules and colour fill plans work straight away.
Finish schedules
Floor, wall and ceiling finishes recorded per room and exported to your schedule format.
Sheet and view set
General arrangement plans, RCPs, sections, elevations and enlarged plans laid out on your titleblock.
Point cloud verification
The registered cloud linked in so anyone can spot check the model against measured data.
Scope of work
What we model in the architecture discipline
Tell us which of these you need. You are never charged for scope you will not use.
Included in every project
- External walls, internal partitions and curtain walls
- Floor slabs, raised floors and floor finishes
- Suspended ceilings, bulkheads and soffits
- Doors, windows, louvres and glazed screens
- Stairs, ramps, handrails and balustrades
- Roof geometry, parapets and rooflights
- Toilets, kitchens and fixed joinery
- Fixed furniture and specialist fit out items
- Room boundaries, names, numbers and areas
- Facade detail including reveals and mouldings
| Scope item | What we deliver | Typical use |
|---|---|---|
| Walls | Compound types with layer thickness matched to the scan | Design changes and material takeoff |
| Openings | Doors and windows as parametric families in real positions | Schedules and procurement |
| Ceilings | Ceiling planes at measured heights with grid layout | RCPs and services coordination |
| Rooms | Bounded rooms with names, numbers and area data | Space planning and leasing |
Working on a fit out where only the shell matters. We can model the base building at LOD 200 and the tenant floors at LOD 350, so the budget goes where the decisions are being made.
How it works
How an architecture model comes together
Floor by floor delivery so your design team is never sitting waiting.
Levels and grids
Floor to floor heights are read from the cloud and levels are set before any geometry is placed.
Shell and core
External envelope, cores, shafts and primary circulation go in first to lock the building frame.
Internal build out
Partitions, doors, ceilings, stairs and joinery are modeled floor by floor against the cloud.
Data and schedules
Rooms are bounded and named, finishes recorded, and every schedule is tested before release.
Sheets and QA
Views are laid out, warnings cleared and a deviation report is produced for your review.
Why clients pick us for this
Native categories
No generic models pretending to be walls.
Your template
We work inside your standards, not a generic one.
Families included
Custom families are built at no extra charge.
Case study
A nine week architecture model for a repositioning project
Commercial · Chicago
The challenge
A 1970s office tower was being repositioned for a new anchor tenant, but the paper drawings on file were incomplete and wrong in several places, and two earlier survey attempts had produced models the design team refused to use.
What we did
We modeled the full architectural shell floor by floor using native wall types, real door and window families and bounded rooms, releasing floors in batches of four so design work could start while later floors were still in production.
The result
Nine weeks end to end
Delivered two days ahead of schedule across all 24 floors
Zero rejected floors
Every release accepted first time by the client BIM manager
4 mm average deviation
Verified against the registered cloud and reported floor by floor
"The model came back inside our template with zero warnings. Our design team started work the same day it landed."
DRD. ReynoldsBIM Manager, Architecture Practice
Questions
Architectural Scan to BIM questions we hear most
Straight answers so you can scope your project with confidence.
Yes, and it is included. Historic doors, unusual windows, bespoke joinery and specialist equipment are built as parametric families with the parameters your team needs for scheduling.
Yes. Older buildings rarely have flat floors or plumb walls. We model the deviation where it matters and tell you where we have straightened geometry for practical reasons.
Yes. Rooms are bounded properly and tested against a measured check before delivery, which matters if the areas feed a lease or a planning submission.
Revit is our main platform and where we are strongest. We also deliver ArchiCAD and clean IFC for teams working in other software.
Yes. Plans, RCPs, sections, elevations and enlarged details are produced from the model on your titleblock, so drawings and model never drift apart.
Related services
Often ordered with this service
Most clients bundle two or three of these to keep one team accountable for the whole scope.
From the blog
Our recent articles
Guides and technical notes from our BIM engineers. Links go live as new posts are published.
AI and LiDAR in Urban Planning: A New Era of Smart Mobility
Learn how AI and LiDAR support urban planning, smart mobility, mapping, and data-driven city development with real-world applications.
Read article
How Leica RTC360 Aligns with Our Vision for Industry-Leading Solutions
Explore how Leica RTC360 supports fast site capture, accurate point clouds, and reliable Scan to BIM workflows for complex projects.
Read article
Using FARO Technology to Simplify Scan to BIM Conversion
Learn how FARO scanning technology supports Scan to BIM conversion by capturing detailed site data for accurate BIM model development.
Read article
Start your project
Send your scan data today. Get a quote tomorrow.
Tell us the building, the area and the level of detail you need. We will come back with a fixed price and a firm delivery date within 24 hours.
